AOS Cine40 V5
The AOS Cine40 V5 is a more powerful guarded prop platform, designed to support up to 4" props and handle heavier camera setups like the Naked BlackMagic Pocket Cinema Kit.
Key Features
Lightweight, Durable Prop Protection
The AOS Cine40 V5 features integrated carbon fiber prop guards that provide durable yet lightweight protection. Reinforced screw holes eliminate weak points in the structure, while optimized airflow around the propellers maximizes propulsive efficiency.
Front and rear GoPro mounting, 90x124 mm Naked BMPCC mounting
The AOS Cine40 V5 supports both forward and reverse camera mounting so you can record the road ahead as well as capture the perfect chase shot with the same drone. It also supports the industry standard Naked BMPCC mounting 90x124 mm.
Durable and Versatile 7075 Aluminum Camera Cage
Protecting your camera, the 7075 aluminum camera cage accommodates all 19-20mm cameras, ensuring broad compatibility with various camera systems. It includes an integrated soft mount specifically designed for the DJI O3 camera, with full ND filter support. For users with different FPV systems, the frame supports hard mounting for all popular camera options, including Analog, WS Avatar, HDZero, and DJI.
Integrated SMA antenna hardpoints
SMA antenna mounts are integrated into the top plate to support larger antennas, ensuring crystal clear video even at longer ranges and eliminating the risk of your battery/camera setup blocking your line of sight to the antenna. The mounting positions are optimized to eliminate vibrations.
Technical Specs
Propeller Support: Up to 4.0" props
Stack Mounting Options: Central 30.5x30.5, 20x20 mm M3 mounting on main plate. Central 25.5x25.5 mm and 20x20 mm M2 mounting on bottom plate.
Field of View: 155° FOV with no props in view
Camera Compatibility: Fully DJI O3 compatible (soft mount + ND filters), supports 19-20mm cameras (hard or soft mounted)
Camera Cage: Reinforced 7075 aluminum construction
Motor Mounting: Supports ⌀16mm M3 motor mounting (compatible with all standard 4" motors)
Recommended motors: 2306, 2207, 2506 (~1800KV for 6S, ~2500KV for 4S)
Full Frame Weight: approx 207 grams
Lightest configuration: approx 154g (without metal camera cage [6g] and prop guards [47g])
GoPro Mounting: 28x28mm M3 GoPro mounting pattern front and rear
Naked BMPCC Mounting: 90 x 124 mm M3 standard pattern
Rear Standoff Spacing: 28mm M3
